Clair Bros. i212-120

Brand: CLAIR BROTHERS (SET)
Quantity:

About this item

• Three-Way Active Line Array Element
• Frequency Response: 45Hz–20kHz Single Cabinet
• Recommended Power Amplifier: 1200W to 1800W @ 8 Ohms
• Max. Output: 144 dB SPL @ 1M Bandpass Dependant; 139 dB SPL @ 1M Full Bandwidth
• Drivers: LF: (2) 12”; MF: (4) 6”; HF: (2) Exit 1.4”; Voice Coil Diameter 3”
• Nominal Impedance: LF: 2 x 8 Ohms, MF: 8 Ohms; HF: 8 Ohms
• Power Handling: LF: 1800W; MF: 720W; HF: 320W
• Dispersion: 90°H x 10°V (Standard); 120°H x 10°V (Optional)
• Input Connection: (2) EP-8 Connectors – 1 Male, 1 Female
• Integral i212 Bimodal Rigging
• Rigging compatible with iS218 Subwoofer
